產品描述
參考號:	1 433 952
華日編號:	HR1320
名稱:	Brake Pad Set
單位:	SET
價格:
Front Axle Brake System : BOS Width : 164.8 mm Height : 66.7 mm Thickness : 18.8 mm

車型	發動機			類型	缸數	年份
比亞迪唐					6/15 - /
TANG 2.0 TI Hybrid	BYD487ZQA	1999	205	Closed Off-Road Vehicle	4	6/15 - /
福特(江鈴) 全順廂式車					3/08 - /
TRANSIT Box 2.3	GZFA	2261	155	Box	4	3/08 - /
福特全順箱式車					4/06 - 8/14
TRANSIT Box (FA_ _) 2.3 16V [RWD]	GZFA	2261	145	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	QVFA	2198	110	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	QWFA	2198	130	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.4 TDCi [RWD]	H9FD	2402	140	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 3.2 TDCi [RWD]	SAFA	3199	200	Box	5	9/07 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	SRFA	2198	115	Box	4	0/08 - 8/14
TRANSIT Box (FA_ _) 2.4 TDCi 4x4	H9FB	2402	140	Box	4	1/06 - 8/14
TRANSIT Box (FA_ _) 2.4 TDCi [RWD]	JXFA	2402	115	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	PGFA	2198	140	Box	4	0/07 - 8/14
TRANSIT Box (FA_ _) 2.4 TDCi [RWD]	PHFA	2402	100	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi [RWD]	DRRA	2198	100	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	CYFA	2198	125	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi [RWD]	CYRA	2198	125	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi [RWD]	CVRA	2198	155	Box	4	0/11 - /
TRANSIT Box (FA_ _) 2.2 TDCi 4x4	CYRB	2198	125	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi	DRFA	2198	100	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.2 TDCi [RWD]	USRA	2198	136	Box	4	0/11 - 8/14
TRANSIT Box (FA_ _) 2.3 16V CNG [RWD]	GZFA	2261	136	Box	4	4/06 - 8/14
TRANSIT Box (FA_ _) 2.3 16V LPG [RWD]	GZFA	2261	145	Box	4	4/06 - 8/14
福特全順巴士					1/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	P8FA	2198	85	Bus	4	4/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	QVFA	2198	110	Bus	4	4/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	QWFA	2198	130	Bus	4	4/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 3.2 TDCi	SAFA	3199	200	Bus	5	2/08 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	SRFA	2198	115	Bus	4	0/08 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	PGFA	2198	140	Bus	4	0/07 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi	CYFA	2198	125	Bus	4	0/11 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi [RWD]	DRRA	2198	100	Bus	4	0/11 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi [RWD]	CYRA	2198	125	Bus	4	0/11 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi	H9FD	2402	140	Bus	4	4/06 - /
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.2 TDCi [RWD]	USRA	2198	135	Bus	4	9/11 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi	JXFA	2402	115	Bus	4	4/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi	PHFA	2402	100	Bus	4	4/06 - 8/14
TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2.4 TDCi 4x4	H9FB	2402	140	Bus	4	1/06 - 8/14
福特全順卡車					4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.3 16V [RWD]	GZFA	2261	145	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDCi [RWD]	JXFA	2402	115	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDCi [RWD]	PHFA	2402	100	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	QVFA	2198	110	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	QWFA	2198	130	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 3.2 TDCi [RWD]	SAFA	3199	200	Platform/Chassis	5	9/07 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	SRFA	2198	115	Platform/Chassis	4	0/08 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDCi 4x4	H9FB	2402	140	Platform/Chassis	4	1/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	PGFA	2198	140	Platform/Chassis	4	0/07 - 9/11
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	DRFA	2198	100	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi [RWD]	DRRA	2198	100	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi	CYFA	2198	125	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi [RWD]	CYRA	2198	125	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi 4x4	CYRB	2198	125	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.2 TDCi [RWD]	CVRA	2198	155	Platform/Chassis	4	0/11 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.3 16V CNG [RWD]	GZFA	2261	136	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.3 16V LPG [RWD]	GZFA	2261	145	Platform/Chassis	4	4/06 - 8/14
TRANSIT Platform/Chassis (FM_ _, FN_ _) 2.4 TDCi [RWD]	H9FD	2402	140	Platform/Chassis	4	4/06 - 8/14
福特全順TOURNEO					0/11 - 8/14
TRANSIT TOURNEO 2.2 TDCi	QVFA	2198	110	Bus	4	7/06 - 8/14
TRANSIT TOURNEO 2.2 TDCi	QWFA	2198	131	Bus	4	7/06 - 8/14
TRANSIT TOURNEO 2.2 TDCi	SRFA	2198	115	Bus	4	0/08 - 8/14
TRANSIT TOURNEO 2.2 TDCi	PGFA	2198	140	Bus	4	0/07 - 8/14
TRANSIT TOURNEO 2.2	CYFA	2198	125	Bus	4	0/11 - 8/14
大眾 AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B)					6/16 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 TDI 4motion	CDBA	1968	122	Pickup	4	9/10 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 TDI	CDBA	1968	122	Pickup	4	9/10 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 BiTDI	CDCA	1968	163	Pickup	4	9/10 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 BiTDI 4motion	CDCA	1968	163	Pickup	4	9/10 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 TSI	CFPA	1984	160	Pickup	4	2/10 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 BiTDI 4motion	CNEA	1968	180	Pickup	4	1/11 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 BiTDI	CNEA	1968	180	Pickup	4	1/11 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 TDI	CNFB	1968	140	Pickup	4	7/12 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 2.0 TDI 4motion	CNFB	1968	140	Pickup	4	6/12 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 3.0 TDI 4motion	DDXC	2967	224	Pickup	6	6/16 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 3.0 TDI 4motion	DDXB	2967	204	Pickup	6	6/16 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 3.0 TDI	DDXA	2967	163	Pickup	6	6/16 - /
AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) 3.0 TDI 4motion	DDXA	2967	163	Pickup	6	6/16 - /
大眾 AMAROK Platform/Chassis (S1B)					9/11 - /
AMAROK Platform/Chassis (S1B) 2.0 TDI	CNFB	1968	140	Platform/Chassis	4	9/11 - /
AMAROK Platform/Chassis (S1B) 2.0 TDI	CNEA	1968	180	Platform/Chassis	4	9/11 - /
AMAROK Platform/Chassis (S1B) 2.0 TDI	CDBA	1968	122	Platform/Chassis	4	9/11 - /
AMAROK Platform/Chassis (S1B) 2.0 TDI 4motion	CNEA	1968	180	Platform/Chassis	4	9/11 - /

建議每5000公里檢查剎車片系統
保證剎車系統正常工作
前剎車片建議在3-5公里內更換，或出現偏磨情況
后剎車片建議在5-7公里內更換

通常遇到以下幾種情況需要更換剎車片:
1、剎車報警器開始報警;
2、剎車片摩擦材料厚度小于3mm;
3、剎車片被制動液或機油浸蝕過;
4、同輪兩側或同軸兩輪的剎車片摩擦不均勻;

通常遇到以下幾種情況需要更換剎車盤:
1、當剎車出現抖動;
2、車輛行駛6萬公里以上，制動存在隱患時;
3、剎車盤磨損超過2mm;
