Description
Ref.:	7 736 572 9
Huari No.:	HR1157- 9
Name:	Brake Pad Set
Unit:	SET
Price:
Front Axle Brake System : ATE Width : 149.5 mm Height : 52.5 mm Thickness : 17.8 mm

Model	Engine			Type	CYL	year
FIAT 500 C					2/13 - /
500 C (312) 0.9	312 A2.000	875	86	Convertible	2	9/09 - /
500 C (312) 0.9	312 A4.000	964	65	Convertible	2	9/12 - /
500 C (312) 0.9	312 A5.000	875	80	Convertible	2	2/13 - /
FIAT 500					7/10 - /
500 C (312) 0.9	312 A2.000	875	86	Convertible	2	9/09 - /
500 C (312) 0.9	312 A4.000	964	65	Convertible	2	9/12 - /
500 C (312) 0.9	312 A5.000	875	80	Convertible	2	2/13 - /
500 (312_) 0.9	312 A4.000	964	65	Hatchback	2	9/12 - /
500 (312_) 0.9	312 A4.000	964	60	Hatchback	2	2/13 - /
500 (312_) 0.9	312 A5.000	875	80	Hatchback	2	2/13 - /
500 (312_) 0.9	312 A2.000	875	86	Hatchback	2	7/10 - /
FIAT GRANDE PUNTO (199_)					6/06 - /
GRANDE PUNTO (199_) 1.3 D Multijet	199 A2.000	1248	75	Hatchback	4	0/05 - /
GRANDE PUNTO (199_) 1.2	169 A4.000	1242	69	Hatchback	4	9/10 - /
GRANDE PUNTO (199_) 1.4	199 A7.000	1368	75	Hatchback	4	6/06 - /
FIAT PUNTO (199_)					7/13 - /
PUNTO (199_) 0.9 Bifuel	312 A2.000	875	86	Hatchback	2	3/12 - /
PUNTO (199_) 1.4 Multi Air	955 A6.000	1368	105	Hatchback	4	3/12 - /
PUNTO (199_) 1.4	350A1.000	1368	78	Hatchback	4	3/12 - /
PUNTO (199_) 1.2	169 A4.000	1242	69	Hatchback	4	3/12 - /
PUNTO (199_) 1.4 Natural Power	350A1.000	1368	78	Hatchback	4	3/12 - /
PUNTO (199_) 0.9 Twinair Turbo	312 A2.000	875	86	Hatchback	2	3/12 - /
PUNTO (199_) 1.3 D Multijet	199 A2.000	1248	75	Hatchback	4	3/12 - /
PUNTO (199_) 1.4 Turbo Multi Air	955 A2.000	1368	135	Hatchback	4	3/12 - /
PUNTO (199_) 1.4 Bifuel	350A1.000	1368	78	Hatchback	4	3/12 - /
PUNTO (199_) 0.9	199 B6.000	875	101	Hatchback	2	2/13 - /
PUNTO (199_) 0.9	199 B6.000	875	105	Hatchback	2	7/13 - /
FIAT PUNTO EVO					0/09 - 2/12
PUNTO EVO (199) 1.4 16V	955 A6.000	1368	105	Hatchback	4	0/09 - 2/12
PUNTO EVO (199) 1.3 D Multijet	199 A2.000	1248	75	Hatchback	4	0/09 - 2/12
PUNTO EVO (199) 1.4 LPG	350A1.000	1368	78	Hatchback	4	6/09 - 2/12
PUNTO EVO (199) 1.4 Natural Power	350A1.000	1368	78	Hatchback	4	0/09 - 2/12
PUNTO EVO (199) 1.2	169 A4.000	1242	69	Hatchback	4	0/09 - 2/12
PUNTO EVO (199) 1.4	199 A7.000	1368	75	Hatchback	4	7/09 - 2/12
PUNTO EVO (199) 1.3 D Multijet	199 B2.000	1248	69	Hatchback	4	7/08 - 2/12
PUNTO EVO (199) 1.2	199 A4.000	1242	65	Hatchback	4	0/09 - 2/12
PUNTO EVO (199) 1.4	350A1.000	1368	77	Hatchback	4	0/09 - 2/12
FIAT PUNTO Van (199_)					3/12 - /
PUNTO Van (199_) 1.4 (199.BXB1A)	350A1.000	1368	78	Box	4	2/06 - /
PUNTO Van (199_) 1.4 Natural Power	350A1.000	1368	78	Box	4	3/09 - /
PUNTO Van (199_) 1.4 LPG (199AXB1A)	350A1.000	1368	78	Box	4	3/09 - /
PUNTO Van (199_) 1.3 D Multijet	199 B1.000	1248	95	Box	4	3/09 - /
PUNTO Van (199_) 1.3 D Multijet	199 B4.000	1248	84	Box	4	3/12 - /
PUNTO Van (199_) 0.9 Twinair Turbo	312 A2.000	875	86	Box	2	3/12 - /

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
