Description
Ref.:	LA01-33-28Z
Huari No.:	HR1146
Name:	Brake Pad Set
Unit:	SET
Price:
Front Axle Brake System : AKB Width : 133 mm Height : 56 mm Thickness : 15 mm

Model	Engine			Type	CYL	year
MAZDA 626 III (GD)					7/87 - 7/91
626 III (GD) 1.8	F8 (12V)	1789	88	Saloon	4	1/87 - 5/92
626 III (GD) 2.0	FE	1998	90	Saloon	4	9/87 - 0/90
626 III (GD) 2.0 12V	FE (12V)	1998	107	Saloon	4	9/87 - 5/92
626 III (GD) 2.0 16V	FE Kat. (16V)	1998	148	Saloon	4	7/87 - 9/89
626 III (GD) 2.0 16V	FE Kat. (16V)	1998	140	Saloon	4	1/87 - 5/92
626 III (GD) 2.0 D	RF-N	1998	60	Saloon	4	7/87 - 7/91
MAZDA 626 III Coupe (GD)					4/88 - 2/91
626 III Coupe (GD) 1.8	F8 (12V)	1789	88	Coupe	4	9/87 - 8/91
626 III Coupe (GD) 2.0	FE	1998	90	Coupe	4	9/87 - 0/90
626 III Coupe (GD) 2.0 16V	FE Kat. (16V)	1998	148	Coupe	4	6/87 - 9/89
626 III Coupe (GD) 2.0 16V	FE Kat. (16V)	1998	140	Coupe	4	2/87 - 0/90
626 III Coupe (GD) 2.2 12V	F2	2184	115	Coupe	4	4/88 - 2/91
MAZDA 626 III Hatchback (GD)					1/87 - 0/90
626 III Hatchback (GD) 2.0 D	RF-N	1998	60	Hatchback	4	7/87 - 7/91
626 III Hatchback (GD) 2.2 12V	F2	2184	115	Hatchback	4	6/88 - 4/92
626 III Hatchback (GD) 1.8	F8 (12V)	1789	88	Hatchback	4	1/87 - 5/92
626 III Hatchback (GD) 2.0	FE	1998	90	Hatchback	4	9/87 - 0/90
626 III Hatchback (GD) 2.0 12V	FE (12V)	1998	107	Hatchback	4	1/87 - 5/92
626 III Hatchback (GD) 2.0 16V	FE Kat. (16V)	1998	140	Hatchback	4	1/87 - 0/90
MAZDA 626 III Station Wagon (GV)					5/91 - 1/92
626 III Station Wagon (GV) 1.8	F8 (12V)	1789	88	Estate	4	1/88 - 3/92
626 III Station Wagon (GV) 2.0	FE	1998	90	Estate	4	0/88 - 9/97
626 III Station Wagon (GV) 2.0 16V	FE Kat. (16V)	1998	140	Estate	4	1/88 - 3/92
626 III Station Wagon (GV) 2.0 D	RF-N	1998	60	Estate	4	9/88 - 7/91
626 III Station Wagon (GV) 2.0 D	RFG5	1998	82	Estate	4	1/94 - 9/97
626 III Station Wagon (GV) 2.0 D Comprex	RF-CX	1998	75	Estate	4	5/93 - 1/96
626 III Station Wagon (GV) 2.0 i 16V	FECM	1998	150	Estate	4	1/94 - 9/97
626 III Station Wagon (GV) 2.2 12V	F2	2184	115	Estate	4	3/89 - 1/96
626 III Station Wagon (GV) 2.2 12V 4WD	F2	2184	116	Estate	4	5/91 - 1/92

Application

MAZDA MPV 1989-1991
MAZDA Vanwagon 1989

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
