  • Description
     43153-SM4-A01
     HRK5524
     Brake Shoe Set
     SET

    Rear Axle
    Brake System : AKEBONO
    Diameter : 220 mm
    Width : 35 mm

Brake Shoe Set:43153-SM4-A01
Model Engine Chassis Type CYL year
HONDA ACCORD IV (CB3, CB7)  1/90 - 3/93
HONDA ACCORD IV Aerodeck (CB)  5/92 - 2/93
HONDA ACCORD IV Coupe (CB, CC)  1/92 - 9/93
HONDA AIRWAVE  6/04 - /
HONDA CAPA  4/98 - 9/02
HONDA CIVIC VI Hatchback (EU_, EP_)  2/01 - 9/05
HONDA CR-V I (RD)  0/95 - 2/01
HONDA FREED I (GB3, GB4, GP3)  3/09 - /
HONDA HR-V (GH)  0/99 - /
HONDA SMX  0/99 - 9/02
SUZUKI CARRY Box (FD)  2/99 - 9/04
SUZUKI JIMNY (FJ)  5/14 - /

Application

HONDA ACCORD CB5-100 2000 R 89' 9-92' 4
HONDA S-MX RH2 2000 4WD 96' 11-02' 1
HONDA S-MX RH1 2000 2WD 96' 11-02' 1
HONDA CR-V RD2 2000 MT 98' 8-01' 9
HONDA CR-V RD2 2000 AT 98' 8-01' 9
HONDA CR-V RD1 2000 "15"" MT" 97' 10-01' 9
HONDA CR-V RD1 2000 95' 10-01' 9
HONDA Stream RN1 1700 2WD 00' 10-06' 7
HONDA Stream RN6 1800 2WD X 06' 7-
HONDA Stream RN2 1700 4WD 00' 10-06' 7
HONDA AIRWAVE GJ2 1500 05' 4-
HONDA AIRWAVE GJ1 1500 05' 4-
HONDA EDIX BE1 1700 FF 04' 7-
HONDA ASCOT CE4 2000 ABS 93' 10-98' 3
HONDA MOBILIO GB2 1500 4WD 01' 12-
HONDA MOBILIO GB1 1500 01' 12-
HONDA MOBILIO GK2 1500 4WD 02' 9-
HONDA MOBILIO GK1 1500 02' 9-
HONDA VIGOR CB5-100 2000 R 89' 10-92' 4
HONDA HR-V GH3 1600 99' 7-
HONDA HR-V GH4 1600 99' 7-
HONDA PARTNER GJ4 1500 4WD 06' 7-
HONDA PARTNER GJ3 1500 06' 3-
HONDA Z PA1 660 4WD 98' 10-00' 1
HONDA CIVIC ES9 1300 01' 12-05' 11
HONDA CIVIC EU1 1500 00' 9-05' 9
HONDA CIVIC EU2 1500 4WD 00' 9-05' 9
HONDA CIVIC FD3 1300 05' 11-
HONDA CIVIC EU4 1700 4WD 00' 9-01' 10
HONDA CIVIC EU3 1700 00' 9-01' 10
HONDA RAFAGA CE4 2000 ABS 93' 10-98' 3
MAZDA SCRUM DG63T 660 05' 9-
MAZDA SCRUM DG63T 660 02' 5-
MAZDA SCRUM DG62T 660 01' 9-
SUZUKI JIMNY JB43W 1300 00' 4-
SUZUKI JIMNY JB33W 1300 98' 1-00' 4
SUZUKI JIMNY JB23W 660 98' 10-
SUZUKI CARRY DA63T 660 05' 9-
SUZUKI CARRY DA63T 660 02' 5-02' 8
SUZUKI CARRY DA62T 660 300001~ 01' 9-


  • Recommends every 5,000 km check Brake System
    ensure the normal operation of the braking system
  • Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
  • Rear brakes is recommended to replace within 5-7 km
  • Replace the Disc brake when follow situation happen:
  • 1.Sensor alarm;
  • 2.Friction materials thickness less than 3mm;
  • 3.Friction materials becomes contaminated with brake fluid;
  • 4.Uneven wear within a set;
  • Replace the brake rote when follow situation happen:
  • 1.Vibrate when braking;
  • 2.Car vehicle performance more than 60000Km and braking unstable;
  • 3.Disc brake thickness wear more than 2mm;
