Description
Ref.:	04495-0D020
Huari No.:	HRK2386
Name:	Brake Shoe Set
Unit:	SET
Price:
Rear Axle Diameter : 200 mm Width : 32 mm

Model	Engine			Type	CYL	year
BYD F0 Hatchback					9/08 - /
F0 Hatchback 1.0	371QA	998	68	Hatchback	3	9/08 - /
CITROEN C1 (PM_, PN_)					06/05 - /
C1 (PM_, PN_) 1.0	1KR-FE	998	68	Hatchback	3	06/05 - /
C1 (PM _, PN _ )1.4 HDi	DV4D	1398	54	Hatchback	4	06/05 - /
JAC YUE YUE					8/12 - 2/15
YUE YUE 1.0	DAK10A	999	68	Hatchback	4	2/10 - 2/13
YUE YUE 1.3	HFC4GB1.3C	1332	99	Hatchback	4	8/12 - 2/15
OPEL AGILA (B) (H08)					4/08 - /
AGILA (B) (H08) 1.0	K10B	996	65	Hatchback	3	4/08 - /
AGILA (B) (H08) 1.2	K12B	1242	86	Hatchback	4	4/08 - /
AGILA (B) (H08) 1.3 CDTI	Z 13 DTJ	1248	75	Hatchback	4	4/08 - /
AGILA (B) (H08) 1.2	K12B	1242	94	Hatchback	4	1/10 - /
AGILA (B) (H08) 1.0 LPG	K10B	996	65	Hatchback	3	1/10 - /
AGILA (B) (H08) 1.2 LPG	K12B	1242	86	Hatchback	4	4/08 - /
PEUGEOT 107					06/05 - /
107 1.0		998	68	Hatchback		06/05 - /
107 1.4 HDi		1398	54	Hatchback		06/05 - /
SUZUKI SPLASH (EX)					1/08 - /
SPLASH (EX) 1.0 (A5B 310)	K10B	996	65	Hatchback	3	1/08 - /
SPLASH (EX) 1.2 (A5B 412)	K12B	1242	86	Hatchback	4	1/08 - /
SPLASH (EX) 1.3 CDTI (A5B 413D)	D13A	1248	75	Hatchback	4	1/08 - /
SUZUKI SWIFT III (SG)					8/05 - /
SWIFT III (SG) 1.3		1328	92	Hatchback	4	02/05 - /
SWIFT III (MZ, EZ) 1.3 4x4 (RS 413)	M13A	1328	90	Hatchback	4	1/06 - /
SWIFT III (SG) 1.3 DDiS	Z13DT	1248	69	Hatchback	4	08/05 - /
SWIFT III (SG) 1.5		1490	102	Hatchback	4	02/05 - /
SWIFT III (MZ, EZ) 1.3 DDiS (RS 413D)	D13A	1248	75	Hatchback	4	8/05 - /
TOYOTA AYGO					07/05 - /
AYGO 1.4 HDi		1398	54	Hatchback	4	07/05 - /
AYGO 1.0	1KR-FE	998	68	Hatchback		07/05 - /
TOYOTA COROLLA Verso (ZER_, ZZE12_, R1_)					4/04 - 3/09
COROLLA Verso (ZER_, ZZE12_, R1_) 1.6 (ZNR10_)	3ZZ-FE	1598	110	MPV	4	4/04 - 3/09
COROLLA Verso (ZER_, ZZE12_, R1_) 1.8 (ZNR11_)	1ZZ-FE	1794	129	MPV	4	4/04 - 3/09
COROLLA Verso (ZER_, ZZE12_, R1_) 2.2 D-4D (AUR10_)	2AD-FTV	2231	136	MPV	4	0/05 - 3/09
COROLLA Verso (ZER_, ZZE12_, R1_) 2.2 D-4D (AUR10_)	2AD-FHV	2231	177	MPV	4	0/05 - 3/09
COROLLA Verso (ZER_, ZZE12_, R1_) 2.0 D-4D (CUR10_)	1CD-FTV	1995	116	MPV	4	4/04 - 3/09
TOYOTA YARIS (_CP10)					0/01 - 9/05
YARIS (_P1_) 1.0 (SCP10_)	1SZ-FE	998	65	Hatchback	4	3/03 - 9/05
YARIS (_P1_) 1.0 (SCP10_)	1SZ-FE	998	68	Hatchback	4	4/99 - 9/05
YARIS (_P1_) 1.3 (NCP10_, SCP12_)	2NZ-FE	1299	86	Hatchback	4	1/99 - 0/05
YARIS (_P1_) 1.3 (SCP12_)	2SZ-FE	1298	87	Hatchback	4	8/99 - 9/05
YARIS (_P1_) 1.4 D-4D (NLP10_)	1ND-TV	1364	75	Hatchback	4	0/01 - 9/05
TOYOTA YARIS VERSO (_P2_)					8/99 - 0/02
YARIS VERSO (_P2_) 1.3 (NCP20_, NCP22_)	2NZ-FE	1299	86	MPV	4	8/99 - 0/02

Recommends every 5,000 km check Brake System
ensure the normal operation of the braking system
Front brakes recommendations within 3-5 km replacement, or partial wear occurs case
Rear brakes is recommended to replace within 5-7 km

Replace the Disc brake when follow situation happen:
1.Sensor alarm;
2.Friction materials thickness less than 3mm;
3.Friction materials becomes contaminated with brake fluid;
4.Uneven wear within a set;

Replace the brake rote when follow situation happen:
1.Vibrate when braking;
2.Car vehicle performance more than 60000Km and braking unstable;
3.Disc brake thickness wear more than 2mm;
